We provide remote production support for mechanical and plumbing contractors. From LOD 300–400 models and custom parametric families to fabrication-ready spool sheets, weld maps, sleeve layouts, and clash-free Navisworks coordination.
LOD 350-400
Fabrication Grade
0 Clashes
Navisworks Matrix
SMACNA / IPC
Standard Compliant
24-48 Hr
Bid Review Window
Full-Scope MEP Detailing & Production
Four focused pillars built specifically for mechanical, plumbing, and piping contractors.
LOD 300–400 parametric 3D modeling for HVAC ductwork, mechanical piping, and gravity/pressure plumbing systems from 2D design packages.
Multi-trade spatial clash detection in Navisworks Manage and Revizto. Proactive clash matrices resolving structural, electrical, and architectural conflicts.
Dimensioned field installation layouts, section cuts, isometric risers, and slab/wall penetration sleeve drawings coordinated with concrete schedules.
Shop-ready fabrication packages segmenting piping into transportable spools with automated cut lists, fitting schedules, and numbered pipe weld maps.
Your Resource. Your Terms.
Flexible, dedicated remote MEP BIM modelers and coordinators structured around your firm’s project pipeline.
Interactive Trade Deliverables
Select a category below to inspect deliverable outputs, specifications, and drawing schedules.
Adjust building size, LOD tier, and required trades to view estimated turnaround benchmark.
Production Benchmark
Firm bid with sheet index delivered within 24-48 hrs.
Autodesk Revit
2020 – 2026Navisworks Manage
Clash MatrixRevizto
Issue TrackingAutodesk ReCap
Point Clouds (RCP)OpenSpace
Site 360 SyncBluebeam Revu
QA MarkupsEngineering Insights & Case Studies
